ED 100 - Door weights up to 160kg, door widths up to 1100mm

ED 250 - Door weights up to 400kg, door widths up to 1600mm



Variable Functional Range

Tested to 1,000,000 cycles, the ED 100/250 is a robust yet elegant electromechanical swing door operator for various fields of application. The 'Wind Load Control' function is ideal for windy sites compensating for heavy wind loads. Suitable for emergency escape routes as well as use on fire and smoke check doors. Apart from the extended cover, dormakaba also provides an easy-to-install integrated door coordinator for double-leaf doors. With the aid of the dormakaba Upgrade Card, the system’s functional range may be adapted to various door versions. The large scope of integrated functions further ensures that the majority of possible applications can be readily accommodated.

​

Door Closer mode & Automatic mode

Users may choose between two operating modes: Door Closer and Automatic mode. While set to the Door Closer mode, the ED 100 / ED 250 swing door operator is optimized for manual operation. With its optional Power Assist function, the Door Closer mode is tailored to predominantly manually operated doors where a door closer function is desired. The Automatic mode in turn is especially suitable for mainly automatic access with motion detector or pushbutton actuation.

​

Wind Load Control

The ED 100 / ED 250 swing door operator is especially suitable for exterior doors that are subjected to varying wind loads and for interior doors separating rooms where different air pressures prevail. While the system is in Automatic mode, the wind load control monitors the actuation speed, keeping it constant at the preset value.
